Quick Preview
Electronic-controlled engine and automatic transmission make operation more convenient and efficient.
The application of information-based and automation technologies makes mining equipment management more efficient.
The perfect combination of lightweight technology and reliability provides the truck with longer service life, lower transport cost and more economical operation.
| Model | TLD96 |
|---|---|
| Manufacturers | Shaanxi Tonly Heavy Industries Co., Ltd. |
| Drive mode | 6×4 |
| Maximum total weight(t) | 105 |
| Rated load mass(t) | 70 |
| Overall mass(t) | 35 |
| Overall size(mm) | 9900×3670×4250 |
| Wheelbase(mm) | 4075+1750 |
| Wheel track(mm) | 2838/2626 |
| Minimum ground clearance(mm) | 400 |
| Minimum turning radius(m) | 11 |
| Maximum height of bucket lift(mm) | 8320 |
| Maximum angle of bucket lift(°) | 50 |
| Loading height(mm) | 4234 |
| Braking distance(m) | |
| Maximum climbing degree(%) | 30 |
| Maximum speed(km/h) | 40 |
| Engine | |
| Model | WP13G530E310 |
| Manufacturer | Weichai Power Co., Ltd. |
| Power(hp/kw) | 530/390 |
| Transmission | |
| Model | 4800 ORS |
| Manufacturer | Allison |
| Input torque（N·m) | 2644 |
| Axle | |
| Manufacturer | Shaanxi Hande AXLE Co., Ltd. |
| Load（t) Front axle +middle axle +rear axl | 25+40+40 |
| Tires / Rims | |
| Tire model | 16.00-25 |
| Rim size | 11.25/2.0-25 |
| Container | |
| Base plate material/thickness(mm) | NM400/16 |
| Rear plate material/thickness(mm) | NM400/12 |
| Front plate material/thickness(mm) | T700/10 |
| Side plate material/thickness(mm) | T700/10 |
| Container capacity(m³) | 36 |
| Hydraulic system | |
| Model | FC191 |
| Manufacturer | HYVA MECHANICS (CHINA) CO., LTD. |
| Steering device | Fully hydraulic steering |
| Container lift time（s) | 27 |
| Container descent time（s) | 17 |
| Weight distribution | |
| No load | |
| Front axle(kg) | 15000 |
| Rear axle(kg) | 20000 |
| Total weight(kg) | 35000 |
| Heavy load | |
| Front axle(kg) | 25000 |
| Rear axle(kg) | 80000 |
| Total weight(kg) | 105000 |
