Quick Preview
| Model | TE700 | ||
|---|---|---|---|
| Operating weight(Kg) | 63600 | ||
| Bucket capacity(m³) | 4.5 | ||
| Engine | Model | CumminsQSM15 | |
| Direct injection | ✓ | ||
| Four strokes | ✓ | ||
| Water cooled | ✓ | ||
| Turbocharged | ✓ | ||
| Air to air intercooler | ✓ | ||
| Number of cylinders | 6 | ||
| Rated power/speed(ISO)(Kw/rpm) | 563/2100 | ||
| Maximum torque/speed(N.m) | 3000/1400 | ||
| Piston displacement(L) | 14.5 | ||
| Main performance | Travel speed(Max/Min)(km/h) | 4.7/3.2 | |
| Swing speed(r/min) | 8.1 | ||
| Gradeability | 70% | ||
| Ground pressure(kpa) | 100.4 | ||
| Bucket digging force(kN) | 364 | ||
| Arm digging force(kN) | 290 | ||
| Maximum tractive force(kN) | 564 | ||
| Hydraulic system | Main pump | Variable pump | |
| Maximum flow of main pump(L/min) | 2X448 | ||
| Relief valve setting pressure(Mpa) | 34.3 | ||
| Travel system pressure(Mpa) | 26 | ||
| Swing system pressure(Mpa) | 26 | ||
| Pilot system pressure(Mpa) | 3.9 | ||
| Oil Capacity | Fuel tank capacity(L) | 850 | |
| Hydraulic tank capacity(L) | 590 | ||
| Engine oil capacity(L) | 31 - 52 | ||
| Outline dimension | A | Total length(mm) | 12167 |
| B | Total height(mm) | 4555 | |
| C | Total width(mm) | 3740 | |
| D | Ground clearance of platform(mm) | 1450 | |
| E | Chassis ground clearance(mm) | 600 | |
| F | Platform tail slewing radius(mm) | 4095 | |
| G | Wheel tread(mm) | 4600 | |
| H | Total track length(mm) | 5725 | |
| I | Track distance(mm) | 2900 | |
| J | Track width(mm) | 3500 | |
| K | Width of track link(mm) | 600 | |
| L | Cab roof height(mm) | 3630 | |
| N | Upper-structure width(mm) | 3415 | |
| Working range | Boom length(mm) | 6600 | |
| Arm length(mm) | 2900 | ||
| a | Max. digging height(mm) | 11290 | |
| b | Max. dumping height(mm) | 7190 | |
| c | Max. digging depth(mm) | 7030 | |
| d | Digging depth (2.44m; horizontal)(mm) | 6880 | |
| e | Max. vertical digging depth(mm) | 4765 | |
| f | Max. digging radius(mm) | 11725 | |
| g | Max. digging reach at ground level(mm) | 11300 | |
| h | Min. front slewing radius(mm) | 5015 | |
