Quick Preview
| Model | Cummins 6CTA8.3 | ||
|---|---|---|---|
| Engine | Type | Direct injection, turbocharged, water cooling | |
| Rated Power | 179KW@2200rpm | ||
| Max.torque | 1028N.m@1500rpm | ||
| Transmission System | ZF electro - hydraulic controlled power shift single handle operation, lock in the neutral. | ||
| Traveling speed (at rated engine rpm) | |||
| Gears | Forward speed | Reverse speed | |
| 1st | 5 | 5 | |
| 2nd | 8.6 | 11.3 | |
| 3rd | 11.3 | 24.3 | |
| 4th | 19.3 | ||
| 5th | 24.3 | ||
| 6th | 38.8 | ||
| Hydraulic System | System pressure | 17.5MPa | |
| Flow rate at engine rated speed | 140L/min | ||
| Steering System | Max.turning range | left or right 49° | |
| Frame articulation | left or right 24° | ||
| Min.turning radius | 8300mm | ||
| System pressure | 16MPa | ||
| Flow rate at engine rated speed | 70L/min | ||
| Axles | Front axle | Ground clearance 610mm and oscillation angle(total)±16° | |
| wheel lean angle | right or left 17° | ||
| Rear axle:full - floating rear axle with NO - SPIN differential | |||
| Tandem Drive | (Tandem oscillation) | 13°forward and reverse | |
| Final driving | Spiral bevel gear, single stage reduction | ||
| Brakes | Service brake | Hydraulic brake system, drum brake | |
| Parking brake | Flexible shaft control actuated inner - ex - panding drum brake | ||
| Moldboard | Dimensions | 4420mmx610mmx20mm | |
| Blade Range | Moldboard side shift | ||
| Right | 965mm | ||
| Left | 965mm | ||
| Max.shoulder reach outside rear tires(frame straight) | |||
| Right | 2150mm | ||
| Left | 2155mm | ||
| Max.lift above ground | 480mm | ||
| Max.grading depth | 500mm | ||
| Max.blade angle right or left | 90° | ||
| Blade tip angle | 29° - 77° | ||
| Tire | Tire size | 20.5 - 25 - 16PR L - 2 | |
| Cabin | Vibration - absorbed humanistic cabin with adjustable steering wheel and seat, streamline dashboard provide low noise, air conditioning, comfortable operation and wide eyeshot. | ||
| Oil Capacity | Fuel tank | 480L | |
| Transmission | 28L | ||
| Crank case | 28L | ||
| Rear axle | 80L | ||
| Tandem housing(each) | 165L | ||
| Hydraulic system | 90L | ||
| Optional Attachment | |||
| Front Blade | Blade width | 2501mm | |
| Max.lift above ground | 579mm | ||
| Max.grading depth | 125mm | ||
| Scarifier | No.of teeth | 11 | |
| Digging width | 1325mm | ||
| Max.lift above ground | 344mm | ||
| Digging depth | 212mm | ||
| Ripper | No.of shanks | 3(max.5) | |
| Max.digging depth | 436mm | ||
| Max.lift above ground | 611mm | ||
| Max.digging width | 2196mm | ||
